ELO 3202L

For more information (specification, configurations and download section) please visit official Elo Touch Solutions website: Link

Colour option
ELO 3202L
Device type
Interactive Digital Signage (IDS)
Elo Touch Solutions 3203L
Touch technologies
Projected Capacitive
Diagonal size
Aspect ratio
Active area (mm)
698.4 x 392.9
Width (mm)
Pro.Cap: 762.8
Height (mm)
Pro.Cap: 457.3
Depth (mm)
Pro.Cap: 50.5
Net weight
Pro.Cap: 12.82 kg
Gross weight
Pro.Cap: 17.47 kg
1920 x 1080
Brightness (sole LCD panel)
450 cd/m²
Brightness (Pro. Cap)
382 cd/m²
Response time
8 ms
Viewing angle
horizontal: 89°, vertical: ±89°
Contrast ratio
Video input - connector
  • HDMI 1.4 x2
  • USB-C (touch + video)
  • DisplayPort 1.2
Touchscreen interface
Power consumption (typical)
Power supply - type
50 000 hours (demonstrated)
Assembly options - Assembly without the base
VESA 400x400mm
Assembly options - available accessories
Wall mount kit, tabletop stand
Other features
Peripherals: magnetic stripe reader, NFC reader, 1D/2D barcode scanner, webcam
36 months
Regulatory approvals and declarations
UL 62368-1, FCC (US), cUL, IC (Canada), CB (International safety) (IEC/EN60950-1+IEC/EN62368-1), CE (Europe), VCCI (Japan), RCM (Australia), CCC, China RoHS (China) (for TouchPro version only), IK07 and UL60950 for ball drop test
Multimedia functions
2 x 5W internal speakers
  • Touchscreen sealed to bezel
  • Touchscreen sealed to LCD
Communication interfaces
1 x 3.5 mm TRS jack Audio Line In, 1 x 3.5mm TRS jack Headphones Out
